High temperature resistance cooling tower PP Material Splash Infill

Cooling tower trickle fill is a type of cooling tower splash fills with wide range of application, the special grid structure design with easy embedded installation could further scatter the spray water to achieve higher heat transfer performance, and made of high quality PP material with high temperature and  chemical resistant, lengthen service life.

FEATURES

1, Made of PP material, high temperature and chemical resistant, suitable for polluted water

quality and cooling industrial water with high temperature drop.

2, Special grid structure design, high security against blockages, cleanable by high pressure

cleaners.

3, Easy to install without glue, steelwire, bolts or any other accessories, high stability due to

mechanical assembly, environment protection

and long service life.

TECHNICAL SPECIFICATION

Model: ZLA-70

Material : PP

Color : Black

Module Length: 908mm

Module Width: 300mm/450mm/620mm

Flute Height: 20mm

Surface Area: 125m2/m3

Max. operating temp. :  95

Installation by the wedged joints of the PP grid sheet.

APPLICATION AND USAGE

Splash grid fills are used to counter flow cooling towers in condition of sewage water , wind tunnel towers, exhaust gas purification towers, dosing platforms, filter ditch cover plates, large sewage treatment pools, special grid packing for large sewage treatment plants, and grass slag baffles waiting venue.  And also widely used in deodorization equipment of farm.
